    320W Outdoor Digital Signage Outdoor Monitor Display Air Cooling Control

    Ask Lasest Price
    Brand Name : USER
    Model Number : US-AD550LHK
    Price : Negotiation
    Delivery Time : 3-8 working days after delivery
    Payment Terms : T/T,L/C,Western Union,Paypal and MoneyGram
    Supply Ability : 1000 Piece/Pieces per Week
    • Product Details
    • Company Profile

    320W Outdoor Digital Signage Outdoor Monitor Display Air Cooling Control

    Kiosk display outdoor digital signage

    Product Description

    outdoor digital signage price

    I. Main features

    1.Patented LED backlight, the brightness can reach as high as 1500nits under strong sunlight (roughly 3 times of other standard products)
    2.Broad working ambient temperature:-25°C to +45°C
    3.The LCD screen can resist condensation in low temperature and humid environment
    4. Outdoor all-weatherproof, dustproof designed + energy-saving air cooled structure

    II. Technical Data Sheet

    Model No.US-AD550LHK
    Panel size55″TFT-LCD
    Display area(mm)/mode1209.6mm(H) x 680.4mm(V) 16:9
    Maximum resolution1920*1080
    Display color1.073G(10bits/color)
    Pixel Pitch(mm)0.21mm(H) x 0.63mm(V) (mm)
    Brightness (nits)800cd/m*m
    Contrast4000:1
    Visual angle178°/178°
    Response time6.5ms
    Life(hrs)>60,000(hrs)
    Touch Panel
    SpecificationInfrared touch
    Positioning
    accuracy
    ±2mms
    Transmittance92%
    Hardness7H
    Click mannerdouble point/mult-point(optional)
    Response time10ms
    Output Resolution4096X4096
    Life timeSingle point of more
    than 600 million times
    Input and output
    VGA input2
    CVBS input2
    YPbPr input1
    TV1
    HD4
    USB2.06
    LAN1
    PC Audio1
    Audio(L/R) input1
    Audio(L/R) output1
    Thermal printer1
    Speaker2×10W(8 ohm)
    Video
    Color systemPAL/NTSC/SECAM
    Remote controllerSpecial
    OSD display( screen menu display)
    Menu languageChinese/English
    Computer
    Main chipsetIntel H61
    CPUIntel I3-3220 3.1GHz
    System bus frequency800/1066/1333 MHz
    Graphics cardIntegrated
    Audio cardIntegrated AC97
    Network cardIntegrated 10/100/1000M adaptive
    MemoryDDRIII 2G (max to 4G)
    Hard Disk32G SATA (max to 1 TB)
    WIFIYes
    BluetoothOptional
    Operation systemWindows/Linux
    Power
    Power supplyAC100~240V 50 /60 HZ
    Maximum power consumption3600W
    Standby power consumption<5W
    Temperature
    Working temperature0℃~50℃
    Storage temperature-20~60
    Working humidity85%
    Storage humidity85%
    Waterproof gradeOutdoor IP34
    Temperature controlAir cooling(Fans)
    Appearance
    Panel color/appearanceWhite, black, customized
    Panel materialMetal case SPCC
    Installationflood-standing/wall mounted
    Pricing(EXW Shenzhen)
    Detailed functions
    Video formatMPEG1/MPEG2/MPEG4/DivX/ASP/WMV/AVI
    Audio formatWave/MP3/WMA/AAC
    Image formatJPEG/BMP/TIFF/PNG/GIF
    Image resolution480P/720P/1080P
    Split screen displayEditable
    Running subtitlelocation, word size, color and backlight are editable
